Emre PTFE Lining is a dependable supplier and producer of FEP and PTFE lined elbows in Turkey. PTFE Lined Elbow that is specifically designed to perform at high levels in highly corrosive and high-temperature environments. Available in both 90-degree and 45-degree configurations, these elbows contribute to fluid flow direction change in a smooth manner while offering superior chemical resistance and mechanical strength. Based in Turkey, we provide durable, precision-finished lined elbows to satisfy the stringent demands of industrial processes. Our in-house manufactured solutions ensure consistent, leak-free operation even under harsh process conditions.
A PTFE lined elbow is a type of pipe fitting to steer the flow in piping systems that handle corrosive or high-purity fluids. It is an outer body of carbon steel or stainless steel with a lining of PTFE (Polytetrafluoroethylene) inside, which offers excellent chemical resistance and non-stick properties. PTFE lined elbows are used extensively in the chemical processing, pharmaceutical, food and beverage, and water treatment sectors. They ensure smooth flow, protection against contamination, and resistance to corrosion even under abusive chemical exposure and at elevated temperatures.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : PFA
Emre PTFE Lining is a leading supplier of PTFE Lined Elbow in Turkey, Istanbul, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
|
NB
|
ID
|
RF
|
OD
|
PCD
|
No.Of Holes x Dia Of Holes
|
Lining Thickness Standard
|
Lining Thickness Full Vacuum
|
Length Max.
|
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Ensures secure and safe flow direction
Performs reliably in elevated heat conditions.
Minimizes turbulence and pressure drop
Handles aggressive chemicals without degradation.
A PTFE-lined elbow is a pipe fitting used to change the direction of fluid flow in a piping system. It has an inner lining made of PTFE (polytetrafluoroethylene), which offers excellent resistance to corrosion and chemical attack.
PTFE-lined elbows are commonly used in industries like chemical processing, pharmaceuticals, food and beverage, and water treatment, where the fluid or gas being transported is aggressive or corrosive.
Yes, they can withstand temperatures up to 230°C, depending on the pressure and application requirements.
Yes, they are non-toxic, hygienic, and ideal for food, beverage, and pharmaceutical applications.
PTFE-lined elbows are typically designed for low to medium-pressure systems. For high-pressure applications, more robust materials or specialized fittings may be required
