Emre PTFE Lining is a leading manufacturer of high-quality PTFE Lined Reducers to work with high performance in critical industrial processes. Based in Turkey, Istanbul, we are a trusted supplier and manufacturer of PTFE, FEP, and PFA lined products for their strength and durability. Our PTFE Lined Reducers are specifically designed to withstand severe chemicals and extreme temperature while maintaining consistent long-term performance and operational efficiency. With superior chemical resistance, rugged construction, and a smooth interior surface, these reducers facilitate smooth transition of flow between various pipe sizes. Being adjustable in shapes, they can be adjusted to suit various process requirements and industry standards.
A PTFE-lined reducer is a specialty pipe fitting to connect two pipes of different diameters with high chemical resistance and flow efficiency. It consists of an internal lining of Polytetrafluoroethylene (PTFE)—a non-reacting, corrosion-resistant substance—and is therefore ideal for use in industries handling aggressive chemicals, acids, or high-purity chemicals.PTFE-lined reducers are used in general application in chemical processing, pharmaceuticals, food and beverage, and water treatment plants. The PTFE lining prevents the process fluid from contacting anything other than the inert surface, reducing contamination and prolonging equipment life. Two general categories of PTFE-lined reducers exist: concentric, whose centerlines are the same, and eccentric, where they are not—both tailored for specific flow applications. They serve an important role generally in maintaining system integrity, maximizing flow transition, and providing a safe and effective operation within adverse industrial processes.
Size : 25 NB to 300 NB
Outer body : ASTM A 395 Gr 60-40-18
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Test : at 29.8 kg/cm2
FEP- Max Temp : 180° C
PP Max Temp : 100° C
PFA Max Temp : 200° C
Emre PTFE Lining is a leading supplier of PTFE Lined Reducer in Turkey, Istanbul, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| NB | L | FLG. | RF | PCD | App. | App. | LINER THK | N x M | WEIGHTS | |
|---|---|---|---|---|---|---|---|---|---|---|
| O / D | O / D | T1 | T1 | Vaccume (T) | Non Vacc (T) | (kg/piece) | ||||
| 1/2″ | —- | 89 | 35.1 | 60.5 | 14.2 | 24.2 | 3.0 | 3.0 | 4 x 1/2″ | 4 |
| 3/4″ | —- | 98 | 42.9 | 69.9 | 15.7 | 27.7 | 3.0 | 3.0 | 4 x 1/2″ | 3.5 |
| 1″ | 89 | 108 | 50.8 | 79.2 | 17.2 | 29.2 | 4.0 | 3.0 | 4 x 1/2″ | 5.5 |
| 1 1/4″ | 95 | 118 | 63.5 | 88.9 | 18.7 | 30.2 | 4.0 | 3.0 | 4 x 1/2″ | 7.7 |
| 1 1/2″ | 102 | 127 | 73.2 | 98.6 | 20.5 | 32.5 | 4.0 | 3.0 | 4 x 1/2″ | 8.7 |
| 2″ | 114 | 152 | 91.9 | 120.7 | 22.1 | 37.1 | 4.0 | 3.0 | 4 x 1/2″ | 14.0 |
| 2 1/2″ | 127 | 178 | 104.6 | 139.7 | 25.4 | 40.4 | 4.0 | 3.0 | 4 x 5/8″ | 20.6 |
| 3″ | 140 | 191 | 127.0 | 152.4 | 27.9 | 42.9 | 4.0 | 3.0 | 4 x 5/8″ | 24.8 |
| 4″ | 165 | 229 | 157.2 | 190.5 | 28.9 | 43.9 | 4.5 | 3.0 | 8 x 5/8″ | 39.1 |
| 5″ | 190 | 254 | 185.7 | 215.9 | 28.9 | 43.9 | 6.0 | 5.0 | 8 x 3/4″ | 68.8 |
| 6″ | 203 | 279 | 215.9 | 241.3 | 30.4 | 45.4 | 6.0 | 5.0 | 8 x 3/4″ | 79.5 |
| 8″ | 229 | 343 | 269.7 | 298.5 | 33.4 | 48.4 | 6.0 | 5.0 | 8 x 3/4″ | 99.0 |
| 10″ | 280 | 406 | 323.9 | 362.0 | 35.7 | 50.7 | 7.5 | 5.0 | 12 x 7/8″ | 160.0 |
| 12″ | 305 | 483 | 381.0 | 431.8 | 37.8 | 52.8 | 7.5 | 5.0 | 12 x 7/8″ | 280.0 |
Withstands harsh acids and solvents.
Prevents fluid leakage at joints.
Suitable for extreme process heat.
Tailored to fit system specifications.
It’s a pipe fitting that transitions between two different pipe sizes, internally lined with PTFE for corrosion resistance.
Common in chemical, pharmaceutical, and corrosive fluid handling systems where size reduction and chemical protection are needed.
Yes, PTFE lined reducers come in both concentric and eccentric configurations to suit different flow requirements.
They’re used in chemical processing, pharmaceuticals, food & beverage, water treatment, and other corrosive service applications.
We offer both concentric (center-aligned) and eccentric (offset) reducers for different flow and installation needs.
